The Model 321 bridge is a through-type steel truss bridge. The truss unit features a Warren truss configuration. The top and bottom chords are made of No. 10 channel steel, while the vertical and diagonal members are fabricated from No. 8 channel steel by welding. The connection module has a length of 3000mm and a height of 1400mm.
Bracing System: Comprises wind ties and vertical struts, connected to the floor beams.
Deck System: Consists of floor beams (28A I-beams) and steel deck panels. Deck panels withstand tracked or wheeled loads directly and are fixed using U-bolts. The maximum achievable span reaches 61 meters, tailored to traffic load requirements.
| Advantage | Description |
|---|---|
| Modular Design | Standardized prefabricated components for flexible combination. |
| Rapid Deployment | Quick response and setup for emergency scenarios. |
| High Efficiency | Shortens construction cycles significantly. |
| Diverse Erection | Compatible with crane hoisting and cantilever launching methods. |
| Relocatability | Structure can be disassembled, transported, and reused. |
| High Strength | Exceptional load-bearing capacity and stability. |
Steel truss girder components are typically shipped as loose items on flatbed trailers or securely fastened in containers. Small parts like bearings, bolts, and tools are packed in reinforced boxes to prevent loss during international transit.
