Product Description

📋 Basic Information

Model NO.

Compact-100/Compact-200

Usage

Footbridge, Highway Bridge, Railway Bridge, Viaduct, Supporting System

Steel Grade

S355/ S460/Gr 55c/Gr350/Gr50/Gr65/GB355/460

Loading Capacity

Hl93/Ha+20hb/T44/Class a/B/MLC110/dB24

Carriage Way Width

3.15m Std. /4.2m Ew/7.35m Double Lanes

Maximum Span

60.96m for Single Lane/45.72m for Two Lanes

Hot DIP Galvanized

ISO1461/AS/NZS 4680/ASTM-A123/BS1706

HS Code

7308100000

🏗 Product Description

Bailey bridge is a type of portable, pre-fabricated, truss bridge. It was developed for emergency use and adopted extensively as the most popular bridge equipment in the world. Features include simple structure, convenient transport, speedy erection, and easy disassembling.

It offers heavy loading capacity, great stability, and long fatigue life. It is capable of alternative spans and various mixture forms to erect temporary, emergency, or fixed bridges.

We maintain three production lines for manufacturing Compact-100 and Compact-200 models. Surface disposal options include painting, galvanizing, or anti-skid wearing (polyurethane bonded bauxite chip system) based on specific requirements. Suitable for load designs: HS-15, HS-20, HS-25, HL-93, and pedrail-50.

Compact-100 Bailey Bridge Truss Allowable Internal Force Table
Bridge Type	Unreinforced Bridge					Reinforce Bridge
Allowable Bending [M](kN·m)	788.2	1576.4	2246.4	3265.4	4653.2	1687.5	3375	4809.4	6750	9618.8
Allowable Shears [Q](kN)	245.2	490.5	698.9	490.5	698.9	245.2	490.5	698.9	490.5	698.9

*Note: Value represents half bridge; full bridge multiplied by 2.

⚙ Technical Specifications

Bridge Types	Compact-200, Compact-100, LSB, PB100, China-321, BSB, Modular bridge (GWD, HBD60, CB300, Delta), Truss, Arch, Suspension, Cable-stayed.
Design Spans	10m to 300m Single span
Carriage Way	Single Lane, Double Lanes, Multilane, Walkway
Standard Compliance	AASHTO HL93, HS20-44, BS5400, AS5100 Truck-T44, IRC 70R, NATO STANAG MLC80/110
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
